Franklin Electric SVM 100 Series 4" Submersible Borehole Pumps - Pump Only
Performance
- Flow rates from 30 l/min to 400 l/min
- Heads up to 290m
Features
- Stainless steel motor adaptor and discharge head for increased
strength and durability. - Polycarbonate impellers, stainless steel bowls and Noryl® diffusers reduce possibility of seizing.
- Built-in check valve to protect the pump against water hammer.
- Impeller design incorporates built-in up-thrust protection.
- Features an 11mm across flats shaft.
Package Content
Pump Only:
This package consists of a pump only.
|
|
PERFORMANCE DATA |
||||||||||
Capacity | |||||||||||
Model |
Motor kW |
Motor Amps |
l/min |
0 |
30 |
45 |
60 |
80 |
90 |
100 |
|
mᶾ/h |
0,0 |
1,8 |
2,7 |
3,6 |
4,8 |
5,4 |
6,0 |
||||
230V |
400V |
l/sec |
0,0 |
0,50 |
0,75 |
1,00 |
1,33 |
1,50 |
1,67 |
||
SVM 10004/037 |
0,37 |
4,0 |
1,1 |
Head (Metres) |
26 |
23 |
22 |
19 |
15 |
12 |
8 |
SVM 10007/055 |
0,55 |
6,0 |
1,6 |
44 |
40 |
36 |
32 |
23 |
17 |
11 |
|
SVM 10010/075 |
0,75 |
7,3 |
2,1 |
65 |
59 |
54 |
47 |
35 |
27 |
18 |
|
SVM 10014/110 |
1,10 |
8,9 |
3,0 |
92 |
84 |
77 |
69 |
51 |
39 |
25 |
|
SVM 10018/150 |
1,50 |
11,1 |
4,0 |
119 |
109 |
100 |
90 |
$
